EOTech EXPS3 HWS
The EXPS3 is the holographic optic people land on when they want three things to be true at the same time: it works with night vision, it mounts fast with a built-in QD lever, and it’s set up for a clean lower 1/3 co-witness height without extra risers.
The quick pitch
-
Night vision compatible with 20 daylight settings plus 10 additional NV settings (Gen I through III+).
-
7mm raised QD base designed for lower 1/3 iron sight co-witness.
-
Side buttons that stay accessible when you’re running a magnifier.
-
CR123 power and a listed 1,000 hours of continuous runtime at nominal setting 12 at room temp.
-
Water resistant to 33 ft (10 m) and rated for -40°F to 140°F operating temps.
What makes the EXPS3 feel different in use
Two eyes open is the whole point. The window and reticle are built around speed and awareness, so you can stay target-focused and still keep the reticle where you want it.
It’s also built to stay in the fight. EOTech calls out the HWS’s ability to keep performing even if the window is damaged or obscured, plus a design that minimizes parallax by projecting the holographic reticle at distance.
Pick the reticle that matches your job
If you’re deciding between models, this is usually the make-or-break section.
0 reticle (68 MOA ring + 1 MOA dot)
The classic “speed ring.” Fast up close, surprisingly precise when you settle into the dot, and the reticle guide notes it provides multiple usable aiming points.
1 reticle (1 MOA dot only)
If you prefer a simpler sight picture (more like a traditional dot) but still want the holographic benefits and big window.
2 reticle (two-dot pattern)
Made to be distinguishable with or without magnification, with multiple usable aiming points based on the referenced load in EOTech’s reticle guide.
4 reticle (ballistic multi-dot)
Optimized around 5.56 NATO/.223 with 62gr M855 from a 14.5" barrel, and EOTech notes the dots may not be clearly distinguishable without magnification.
DCR reticle
A ring with a top cutout plus a bottom chevron meant to give a fast close-range solution while keeping confident aiming points out to distance (per the reticle guide’s 50-yard zero reference).
Specs people actually care about
- Size: 3.8" x 2.3" x 2.9"
- Weight: 11.2 oz
- Mount: 1" Weaver or MIL-STD-1913 rail
- Adjustments: 0.5 MOA per click
- Brightness: 20 daylight + 10 NV settings
- Power: 1x CR123
- Battery life: 1,000 continuous hours at nominal setting 12 at room temp
- Water resistance: 33 ft (10 m)
- Operating temp: -40°F to 140°F
- Country of origin: Made in USA
What’s in the box
-
Optic
-
CR123 battery
-
Warranty card
-
Quick start guide
Warranty and credibility signals
The EXPS3 product page calls out a 10-year warranty and notes the HWS line being awarded “Close Combat Optic” for USSOCOM.
For the warranty terms breakdown (including coverage structure), EOTech’s warranty info page provides the details.
FAQ
Is the EXPS3 night vision compatible?
Yes. It includes 20 daylight settings plus 10 additional settings intended for Gen I through III+ night vision devices.
What battery does the EXPS3 use?
One CR123 battery.
How long is the battery life?
EOTech lists 1,000 continuous hours at nominal setting 12 at room temperature.
Is it waterproof?
It’s rated water resistant to 33 ft (10 m) depth.
Will it fit a Picatinny rail?
Yes. The mount is listed for 1" Weaver or MIL-STD-1913 rails.
What does “lower 1/3 co-witness” mean here?
EOTech describes the EXPS3 as using a 7mm raised QD base intended for lower 1/3 iron sight co-witness, so your irons sit in the lower portion of the optic window instead of dead center.
Which reticle should I choose if I’m adding a magnifier?
If you want hold points and you’ll actually use magnification, the reticle guide notes the 4 reticle is optimized around a ballistic setup and also mentions the dots may not be clearly distinguishable without magnification.
| Specifications | |
|---|---|
| Length: | 3.8 in (96.5mm) |
| Width: | 2.3 in (58.4mm) |
| Height: | 2.9 in (73.7mm) |
| Weight: | 11.2 oz (317.5g) |
| Mount: | 1" Weaver or Mil-Std 1913 rail |
